FPGA vs Microcontrollers

Originally published on Medium.

Introduction

FPGA (Field-Programmable Gate Array) and Microcontrollers are both essential components in the world of embedded systems and electronics, used to control and process tasks in various applications. However, they differ fundamentally in their design and purpose.

FPGA is a reconfigurable semiconductor device that consists of an array of programmable logic blocks and interconnections. Engineers can design custom digital circuits by configuring the FPGA to perform specific tasks. This flexibility allows FPGAs to handle high-speed parallel processing and execute multiple operations simultaneously, making them ideal for applications that require customized logic, signal processing, or high-speed data transfer, such as video processing, telecommunications, and complex algorithms.

Microcontrollers, on the other hand, are compact integrated circuits (ICs) designed for specific control applications. They include a central processing unit (CPU), memory (both volatile and non-volatile), and peripherals integrated into a single chip. Microcontrollers are optimized for running pre-defined software or firmware, making them well-suited for tasks like controlling sensors, managing communication protocols, or operating simple consumer electronics.

Comparison: FPGA vs. Microcontroller

Architecture and Flexibility:

• FPGA: Highly flexible and configurable. The hardware logic inside an FPGA can be reprogrammed to perform virtually any digital function. This flexibility allows engineers to design custom data paths and implement highly parallel operations.
• Microcontroller: Comes with a fixed hardware architecture. It has a specific set of peripherals, memory layout, and a processor core, which limits its ability to be customized. Instead, it is programmed with software that uses the existing hardware features.

Performance:

• FPGA: Can achieve higher performance, especially for parallel and time-critical operations, because the logic can be executed simultaneously without being limited by sequential execution. FPGAs are ideal for applications requiring high-speed signal processing, real-time data handling, or specific timing requirements.
• Microcontroller: Generally slower in execution because tasks are performed sequentially by the processor core. Microcontrollers are sufficient for applications that do not demand extremely high processing speeds or strict timing, such as controlling LED lights, reading sensors, or running communication protocols.

Development Complexity:

• FPGA: Development requires knowledge of hardware description languages (HDLs) such as Verilog or VHDL. Designing, simulating, and debugging hardware logic is more complex compared to writing software code. Additionally, FPGA development tools and workflows are specialized and may have a steeper learning curve.
• Microcontroller: Easier to develop for, as programming can be done using higher-level languages like C or C++. The process involves writing firmware to run on the microcontroller and is more straightforward, with widely available libraries and development environments.

Cost and Power Consumption:

• FPGA: Generally more expensive and power-hungry compared to microcontrollers. The cost is justified in applications where performance or flexibility is critical, but it may not be suitable for cost-sensitive or battery-powered designs.
• Microcontroller: Cost-effective and efficient in terms of power consumption, making them ideal for low-power or battery-operated devices. They are widely used in applications where minimizing cost and power usage is a priority.

Use Cases:

• FPGA: Ideal for high-performance applications like video encoding/decoding, software-defined radio, cryptography, real-time data processing, and custom DSP (Digital Signal Processing) tasks.
• Microcontroller: Commonly used in home automation, consumer electronics, automotive control systems, medical devices, and simple IoT applications.

Reconfigurability:

• FPGA: Can be reprogrammed multiple times, making it suitable for prototyping or applications that require regular updates to the hardware functionality. This feature is beneficial for iterative development and projects with evolving requirements.
• Microcontroller: Hardware functionality is fixed, though the firmware can be updated. Suitable for applications where hardware features are well-defined and unlikely to change over time.

Conclusion

FPGAs and microcontrollers serve different purposes in embedded system design. FPGAs excel in performance, parallel processing, and customizability but are complex and costly. Microcontrollers are simpler, cost-effective, and more power-efficient, making them ideal for control-oriented tasks and everyday embedded applications. The choice between FPGA and microcontroller depends on the application’s performance, cost, power constraints, and design complexity.

Practical Use of FPGA and Microcontroller: Cheque Scanner Example

In real-world applications, FPGAs and microcontrollers are often used together to leverage the strengths of both technologies. A cheque scanner is an excellent example of this collaboration, where tasks are divided between an FPGA and a USB3 microcontroller to optimize performance and efficiency.

Cheque Scanner System Overview:

• The cheque scanner is responsible for capturing high-resolution images of cheques, managing the physical movement of cheques through the scanning path, and ensuring reliable data transfer to a host computer.
• The system is designed to handle tasks that require high-speed data processing and precise motor control.

Role of USB3 Microcontroller:

The USB3 microcontroller handles the high-level scanning tasks and USB management. It acts as the main interface between the cheque scanner and the host computer, ensuring smooth communication and data transfer.

Key responsibilities of the USB3 microcontroller include:

• Managing the USB protocol to transfer scanned images efficiently.
• Handling command and control operations, such as starting or stopping the scan.
• Performing high-level processing tasks, like image formatting or compression, before sending the data to the host.

Role of FPGA:

The FPGA manages the scanning CIS (Contact Image Sensor), stepper motors, and ADC (Analog-to-Digital Converter) sampling in parallel. These tasks require precise timing and simultaneous operations, which are well-suited for FPGA’s parallel processing capabilities.

Key responsibilities of the FPGA include:

• Controlling the scanning CIS to capture high-speed image data and processing the data in real-time.
• Driving the stepper motors to ensure smooth and accurate movement of the cheque through the scanning path.
• Managing ADC sampling to monitor sensor data, such as the cheque’s position or quality of the image capture.
• Performing low-level signal processing, such as filtering or data synchronization, before passing it to the USB3 microcontroller.

Why This Approach Works:

• The USB3 microcontroller is ideal for managing high-level operations and interfacing with the computer, as it is designed for efficient handling of communication protocols and processing complex software tasks.
• The FPGA excels at handling tasks that require precise control and parallelism. By managing the CIS, motors, and ADC in parallel, the FPGA ensures high-speed and accurate scanning, which is crucial for a system that needs to process large volumes of data quickly.

This combination of an FPGA and a microcontroller in a cheque scanner system illustrates how these technologies complement each other to achieve high performance and efficiency. The FPGA takes care of time-critical, parallel tasks, while the microcontroller manages communication and high-level control.
